5086 O H111 Aluminum Sheet

5086 O H111 Aluminum Sheet

Tensile Strength: ≥240 MPa
Yield Strength: ≥100 Mpa
Specification: EN 485-2
Corrosion resistance: High

5086 aluminum exhibits excellent corrosion resistance and moderate strength. Its weldability is an advantage.

It is used in transportation, pressure vessels, low-temperature applications, towers and drilling rigs, natural gas/petroleum pipelines, military equipment, and armored plates.

Sizes of 5086 aluminum plates

W*L: 4" x 8", 12" x 12", 18" x 12", 24" x 12", 24" x 24", 36" x 12", 36" x 24", 36" x 36"

Description Thinness
5086-O Aluminum Sheet 0.032" 0.032"
5086-O Aluminum Sheet 0.040" 0.040"
5086-O Aluminum Sheet 0.050" 0.050"
5086-O Aluminum Sheet 0.063" 0.063"
5086-O Aluminum Sheet 0.080" 0.080"
5086-O Aluminum Sheet 0.090" 0.090"
5086-O Aluminum Sheet 0.100" 0.100"
5086-O Aluminum Sheet 0.125" 0.125"
5086-O Aluminum Sheet 0.160" 0.160"
5086-O Aluminum Sheet 0.190" 0.190"
5086-O Aluminum Plate 0.250" 0.250"
5086-O Aluminum Plate 0.313" 0.313"
5086-O Aluminum Plate 0.375" 0.375"
5086-O Aluminum Plate 0.500" 0.500"
5086-O Aluminum Plate 0.625" 0.625"
5086-O Aluminum Plate 0.750" 0.750"
5086-O Aluminum Plate 1.000" 1.000"
5086-O Aluminum Plate 1.250" 1.250"
5086-O Aluminum Plate 1.500" 1.500"
5086-O Aluminum Plate 2.000" 2.000"

Material properties of aluminum 5086 O plate sheet

Specified thickness Rm (MPa) Rp0,2 (MPa) A % Bending radius Hardness HBS
More than Until mini maxi mini A 50 A 180° 90°
0,2 0,5 240 310 100 11 1,0 e 0,5 e 65
0,5 1,5 240 310 100 12 1,0 e 1,0 e 65
1,5 3,0 240 310 100 13 1,0 e 1,0 e 65
3,0 6,0 240 310 100 15 1,0 e 1,5 e 65
6,0 12,5 240 310 100 17 2,5 e 65
12,5 150,0 240 310 100 16 65

Chemical composition of 5086 aluminum plates

Element Chemical Element
Manganese (Mn) 0.40-1.00
Iron (Fe) 0.40 max
Copper (Cu) 0.10 max
Magnesium (Mg) 4.00-4.90
Silicon (Si) 0.0-0.40
Zinc (Zn) 0.0-0.10
Chromium (Cr) 0.05-0.25
Titanium (Ti) 0.15 max
Other (Each) 0.0-0.05
Others (Total) 0.0-0.15
Aluminium (Al) Balance

Processing properties

Processing Properties Metric
Annealing Temperature 343 °C
Hot-Working Temperature 316 - 482 °C

Welding performance

When welding 5083 to itself or another alloy from the same sub-group, the recommended filler metal is 5183. Other suitable fillers are 5356 and 5556.

Weldability – Gas Weldability – Arc Weldability – Resistance Brazability Solderability
Average Excellent Excellent Poor Poor


Anodizing of 5086 aluminum plate

Bright anodizing Coloured anodizing Hard anodizing Protecting anodizing
Not recommended Not recommended Satisfactory Good

Corrosion of 5086 plate

General corrosion index Corrosion in industrial atmosphere Corrosion in sea atmosphere Corrosion in country atmosphere Corrosion under stress Exfoliation index Intercrystalline corrosion Tapping index
Very good Very good Very good Very good Good Very good Good Very good

Applications of 5086 O H111 aluminum

  • Shipbuilding
  • Patrol and workboat hulls
  • Rail vehicles
  • Dump truck bodies
  • Mining skips and cages
  • Pressure vessels
  • Tank trucks

Advantages of 5086 aluminum plate

  • Higher strength compared to 5052 or 5083
  • Good corrosion resistance
  • Precise dimensions
  • Able to withstand high-pressure and high-temperature loads
  • Rust-resistant treatment
  • Ensures a good stress distribution
  • Mechanical properties may vary significantly due to hardening and temperature.
